Aluminum Housing Fanless Mini Embedded PC 2RJ45 / 4USB RS232 RS485

Name: Aluminum Housing Fanless Mini Embedded PC 2RJ45 4USB RS232 RS485
Brand: ITD/OEM
Price: 1 USD

China Aluminum Housing Fanless Mini Embedded PC 2*RJ45 / 4*USB RS232 RS485 wholesale

Brand Name : ITD/OEM

Model Number : ITD-MNPC-N2830

Certification : CE, FCC, RoHS

Place of Origin : China

MOQ : 1PCS

Price : TBA

Payment Terms : T/T, Western Union, Paypal

Supply Ability : 10000PCS/Month

Delivery Time : 5-15 Business Days

Packaging Details : 1-5pcs/CTN, Safe, Firm, suitable for international shipping

Housing Material : Aluminum housing

Color : Black

Housing Type : VESA Mounting, side mounting

MTBF : 50000Hours

Operating Temperature : -10~60℃(-20~70℃ optional)

Operating Humidity : 10%-90% (Non Condensing)

24/7/365 Use : Supported

Contact Now

Fanless low power industrial embedded box mini PC computer Intel Celeron N2830 WIFI 2*RJ45 4*USB RS232 RS485

ITD Industrial Embedded Box PC is ultra-compact industrial computer for repetitive machines and infrastructures. It utilizes an Intel® Celeron® Processor N2830, on-board non-volatile DDR3L-1333 memory and a standard SD card slot. This delivers a great combination of performance, features and functionality at an affordable price, which offer real-time performance, compact footprint and lightweight aluminum die-cast housing and are easy to service, maintenance-free, space-saving and fan-less.

BENEFITES

IoT gateway ready for future requirements
Energy-efficient and fan-less IPC Systems
Intel Celeron® N2930, 2M Cache, 2.16 GHz
Maintenance-free with no rotating disk (HDD)
Robust aluminum die-casting housing
Power-optimized PC with 32- or 64-bit OS
High system availability and data security
High data transfer rates and redundancy

Industrial Embedded Box PC
Model Name	ITD-MNPC-N2830
IP Rating	N/A
PC Systems
CPU	Intel® Celeron N2830 Dual-Core 2.16GHz Processor
Chipset	Intel® NM70
Graphics	Intel NM70 Express HD Graphics
Audio	MIC-IN, LINE-OUT
Memory	2GB, up to Max. 8GB
Storage	320GB SATA up Max. 1TB; 32GB SSD up to Max. 512GB (MSATA Supported)
Driver Support	Windows CE/XP/7/8/10, Linux,
I/O
Serial Ports	6 x COM
USB Ports	6 x USB2.0, 2 X USB3.0
HDMI Port	1 x HDMI
VGA Port	1 x VGA
TF Card Slot	1 x TF Card Slot
SD Card Slot	1 x SD Card Slot
Mini PCIe	N/A
Audio	MIC-IN, LINE-OUT
Communication (3G/4G, WIFI)	Optional
LAN	1 x 10/100/1000Mbps Ethernet
Power Port	1 x DC 12V Input (1 x ON/OFF Power Switch)
Power
Power Indicator	Green LED
Power Input	DC 12V
Power Consumption	TBA
Operation/Mechanical
Operating Temperature	-10~60℃
Humidity Range	20%~90% (Non Condensing)
Housing Material	Aluminum Die-Casting
Housing Dimension (L × W × H	216mm x 200mm x 55mm

Aluminum Housing Fanless Mini Embedded PC 2*RJ45 / 4*USB RS232 RS485

APPLICATION
