| Wall-Mounted Digital Signage LCD Display
|
| Model Name | ITD65ADG1** |
| IP Rating | IP65 Front Panel Optional |
| Single Media Player Option
|
| 1 ×USB 2.0, 1×CF Card Slot, 1×SD Card Slot
Video Formats Supported: MP4, AVI, DAT, MPG, RM, RMVB, AVC, FLV
Audio Formats Supported: MP3, WMA, OGG, AAC, AC, DTS, FLAC, APE
Picture Formats Supported: JPEG, BMP, GIF, PNG
File Formats Supported: FAT, FAT32, NTFS |
| PC Systems Options
|
| ARM Android Based RK3288(RK3368 optional) | X86 Windows Based | X86 Windows Based |
| CPU: Quad-Core Cortex-A17 1.8GHz | CPU: Intel® Celeron J1900 | CPU: Intel Core i3/i5/i7 |
| Chipset: N/A | Chipset: Intel® NM10 Express | Chipset: Intel® HD Graphics, Support 1080p |
| Memory: 1G/2G | Memory: 2GB(Max. 8GB) | Memory: 2GB(Max. 8GB) |
| HDD/SSD: 8G | HDD/SSD:500G/64G | HDD/SSD:500G/64G |
| 1×HDMI | 1×VGA, 1×HDMI | 1×VGA, 1×HDMI |
| 1×USB 2.0 | 2×USB 2.0, 2×USB3.0 | 2×USB 2.0, 2×USB3.0 |
| 1×mini-SD slot | 1×COM(RS232/422/485) | 1×COM(RS232/422/485) |
| 1×LAN | 1×LAN | 1×LAN |
| 1×Audio Out | 1×Audio Out, 1×MIC In | 1×Audio Out, 1×MIC In |
| Expansion: SSD | Expansion: USB, COM, Mini-PCIe | Expansion: USB, COM, Mini-PCIe |
| LCD Panel
|
| Screen Diagonal (Inch) | 65” |
| Display Active Screen Size (cm) | 1428.48(H)×803.52(V) |
| Aspect Ratio | 16:9 |
| Physical Resolution | 1920×1080 |
| Maximum Resolution Supported | 1920×1080 |
| Colors | 16.7M |
| Brightness (cd/m²) | 400 |
| Contrast Ratio | 1400:1 |
| View Angels | 89/89/89/89 |
| Backlight/Backlight Lifetime | LED Backlight with 50000Hours'Lifetime |
| Touch Panel Available for Network Version
|
| Touch Options | IR, PCAP, Touch Foil |
| Touch Drivers | Windows, Linux, Android, Mac, Raspberry Pi |
| Operation
|
| Operating Temperature Range | 0~50°C |
| Humidity Range (RH) | 10-90% |
| 24/7/365 Use | Supported |
| Power /Speakers
|
| Power Indicator | Green LED |
| Power Input | Internal Power Supply, AC 100V~240V |
| Power Consumption
Speakers | 260W
2×5W |
| Order Information
|
| 65”Free Standing Single Digital Signage | ITD65ADG1LA1 |
| 65”Free Standing Android Network Digital Signage | ITD65ADG1LE1 |
| 65”Free Standing Windows(J1900) Network Digital Signage | ITD65ADG1LJ1 |
| 65”Free Standing Windows(Intel i3) Network Digital Signage | ITD65ADG1LC1 |
